How many two input nand gates are required to make a four input nand gate?

+1 vote
58 views

How many two input nand gates are required to make a four input nand gate, explain with an example?

posted Jul 20, 2017 by anonymous

Share this question
Facebook Share Button Twitter Share Button LinkedIn Share Button

1 Answer

0 votes

Five

Four input nand gate can be defined as Q=!(A.B.C.D) and can be represented using the two input nand gate as follows-
enter image description here
Image Source: internet

answer Jul 21, 2017 by Salil Agrawal
